DSE Series Single Screw Extruder
DSE Single screw extruder adopt most advanced design idea of single screw , the materials are to be excellent dispersed and high homogeneously kneaded causing the sharp shearing and kneading acted by the screw shaft with high speed complex movement of bogh rotary and reciprocal moving . The machine has designed in consideration of the reliability and safety when the machine works with high speed. The protect system guarantees the machine work under the optimum condition and provides reliable protection to the machine and the operator.
Main Features
¡ô High homogeneous kneading and excellent dispersion
¡ô High output
¡ô High Efficient heat exchange
¡ô Single screw force feeding system
¡ô Feed volume controlled automatically
¡ô Electrical Controlled by PLC(option)
¡ô Metal particle detector (option)
¡ô Steady performance
¡ô Easy to clean and maintain
¡ô Safe to operation
| Model | Screw Dia
(mm) | Screw Length
(mm) | Motor Power
(kw) | Screw Speed
(rpm) | Output
(kg/hr) | Heating Type | Heating Power
(kw) |
| DSE-30 | 30 | 90 | 5.5 | 0-500 | 40-60 | Water | 4 |
| DSE-46 | 46 | 90 | 22 | 0-500 | 150-180 | Water | 8 |
| DSE-70 | 70 | 110 | 55 | 0-500 | 400-500 | Water | 2*9=18 |
| DSE-100 | 100 | 110 | 90 | 0-500 | 800-1000 | Water | 2*9=18 |
